Problem : / 1

#PROBLEM-59157

#PROBLEM-59157

The following figure shows a circuit consisting of 8 resistors. Which of the following statements is correct? Choose 3 correct options.

Try to answer the question using the currently displayed hint. The next hint will be available shortly.

\(R_4\) and \(R_2\) are connected in seres.

\(R_1\) and \(R_2\) are connected in parallel.

\(R_4\) and \(R_5\) are connected in series.

\(R_1\) and \(R_5\) are connected in parallel.

\(R_3\) and \(R_4\) are connected in series.
